4.0V 220mAh sealed Lithium Supercapacitor Cell Energy Storage

Model Number : LSC1550

Certification : CE, ROHS, UN38.3

Place of Origin : Wuhan

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 10000PCS/30Days

Delivery Time : 20 Days

Packaging Details : Carton

Product System : Lithium Supercapacitor Cell

Nominal Capacity(3.67V) : 220mAh

Nominal Voltage : 4.0Volt

Internal Resistance : ≤150mΩ

Operating Temperature : ﹣40℃～+85℃

Weight : About 21g

Applications : Remote/Wireless, Intelligent Fire Control System

Contact Now

4.0V 220mAh Sealed Lithium Supercapacitor Cell Energy Storage

Lithium Supercapacitor Cell Features

The Lithium super capacitor is a composite super-capacitor fabricated by hybrid lithium ion secondary batteries electrode materials, including graphite, lithium cobalt oxide, lithium iron phosphate, and metal oxides, with an activated porous carbon with high specific surface area. Due to the addition of lithium-ion batteries electrode materials, the energy storage mechanism of the composite super-capacitors is no longer the traditional nonaradic double-layer charge storage mechanism.

Lithium Supercapacitor Cell Performance Data

Product System	Lithium Supercapacitor Cell
Model	LSC1550
Nominal Capacity(4.0V)	220mAh
Nominal Voltage	4.0V
Internal Insistance	≤150mΩ
Max. Continuous Discharge Current	2000mA
Max. Pluse Current	5000mA
Max. Charge Current	1000mA
Max. Charge Voltage	4.0V
Discharge End Voltage	2.5V
Operating emperature	﹣40℃～+85℃
Weight	About 21g

Lithium Supercapacitor Cell Characteristic Curve

4.0V 220mAh sealed Lithium Supercapacitor Cell Energy Storage

Discharge Curve at 25℃

4.0V 220mAh sealed Lithium Supercapacitor Cell Energy Storage

Advantages

1. It can realize instantaneous large current discharge

2. Long-life energy storage device

3. Fully sealed structure and wide working tem perature range,

4. Suitable for long-term use in harsh environments.
